If an error occurs with the machine, one of the following error codes appears in the LCD display.
In case of a trouble, immediately contact your local dealer for inspection and repair.
№ |
LCD display |
LED |
Problem / Error |
Solution #1 |
Solution #2 |
1 |
The Controller Area Network (CAN) has developed a fault. Measured values may be incorrect and switches may not function |
The machine can be started and driven. Do not perform any work with the machine. |
Inform your KUBOTA dealer immediately |
||
2 |
Feed fuel |
This message appears when the fuel level is low and prompts the operator to refuel
|
- |
Refuel the excavator. |
|
3 |
Periodic check soon (notice) |
|
This message appears 10 hours before the periodic check interval. This message means that the regular service is due shortly. |
Operate the machine as usual. |
Ask your KUBOTA dealer about the relevant parts. Run the maintenance procedure. |
4 |
Periodic check passed (warning) |
This message means that the regular service is due |
The machine can be operated but service must be carried out urgently |
Ask your KUBOTA dealer about the relevant parts. Run the maintenance procedure |
|
5 |
Warning temperature Rising
|
|
The temperature of the coolant is higher than normal. |
Operate the machine only with reduced loads until the temperature is normal again |
- |
6 |
- |
- |
- |
- |
- |
7 |
- |
- |
- |
- |
- |
8 |
- |
- |
- |
- |
- |
№ |
LCD display |
LED |
Problem / Error |
Solution #1 |
Solution #2 |
9 |
Clock setting request |
Power was interrupted and the clock now has to be set again. |
In order to set the clock, press the user setting switch. |
- |
|
10 |
- |
- |
- |
- |
- |
11 |
Raise the control lever Lock |
Yellow
|
This message indicates a step in a procedure |
Raise the lock lever (unload lever); the indicator goes out. |
- |
12 |
Pull out the key |
The key must be pulled out |
Pull out the key |
- |
|
13 |
Lower the control lever Lock |
Yellow |
This message indicates a step in a procedure. |
Lower the lock lever (unload lever); the indicator goes out |
- |
14 |
Oil pressure too low |
Red |
The engine oil pressure is too low |
Stop the engine immediately. The engine may have developed a fault |
Inform your KUBOTA dealer immediately |
15 |
Overheat |
The machine is overheated and must cool off by idling. |
Allow the machine to cool off by idling. Do not switch the engine off as the coolant could then boil over. |
Clean the radiator and check the coolant. Refi ll the radiator with coolant by its boiled-over amount. Unclog the radiator and other components before use again. Check also the hydraulic system for oil leak and other troubles. If an oil leak is found, immediately contact your local dealer for repair |
|
16 |
Charging system error
|
|
The charging system has developed a fault. |
Check the V-belt. When the V-belt is OK, let the engine run until the indicator goes out. |
If the indicator does not go out, inform your KUBOTA Dealer immediately. |
№ |
LCD display |
LED |
Problem / Error |
Solution #1 |
Solution #2 |
17 |
Fuel sensor error |
The fuel sensor has developed a fault; the fuel gauge does not appear in the display |
Press the display selector switch to return to the default display |
Inform your KUBOTA dealer immediately. |
|
18 |
Water temperature sensor error
|
|
The coolant temperature sensor has developed a fault; the coolant temperature gauge does not appear in the display. |
Press the display selector switch to return to the default display. The functions of the machine are stable but overheating cannot be excluded. |
Inform your KUBOTA dealer immediately. |
19 |
- |
- |
- |
- |
- |
20 |
Lever lock system error |
The electrical system in the lock lever (unload lever) has developed a fault. |
The engine can be started but the machine cannot be set in motion. |
Inform your KUBOTA dealer immediately. |
|
21 |
Travel 2 speed system Error |
The electrical system in the travel speed has developed a fault |
The machine can only be set in motion at low speed. |
Inform your KUBOTA dealer immediately. |
|
22 |
- |
- |
- |
- |
- |
23 |
- |
- |
- |
- |
- |
24 |
- |
- |
- |
- |
- |
№ |
LCD display |
LED |
Problem / Error |
Solution #1 |
Solution #2 |
25 |
Overvoltage |
|
This is a warning that a higher voltage (from a 24-Vbattery, for example) is being applied to the electric circuit, or that there is a problem with the alternator. |
Switch the engine off immediately and check the battery and the alternator. Restart the engine. |
If the indicator lights up again after restarting, inform your KUBOTA dealer immediately |
26 |
- |
- |
- |
- |
- |
27 |
External 5-V system error
|
|
The 5-V sensor supply line has developed a system fault. The main functions are not available |
The machine can be started and driven. Do not perform any work with the machine |
Inform your KUBOTA dealer immediately. |
28 |
External 12-V system error |
The 12-V sensor supply line has developed a system fault. The main functions are not available. |
The machine can be started and driven. Do not perform any work with the machine |
Inform your KUBOTA dealer immediately |
|
29 |
Starting the engine |
|
This error code indicates a step in a procedure. |
Start the engine; the indicator goes out. |
- |
Service hour meter (MODEL U17)
When the hour meter has
counted up to the hours circled in the maintenance list below, the
message appears. The message shows up as follows.
